Anthem MDX 8 Power Amplifier
Meet The Engineering Team Behind The MDX
Anthem’s research and engineering division, sequestered in the epicentre of the Canadian tech industry, Ottawa, Canada, is the driving force behind the revolutionary MDX Series. Anthem’s Engineers spent over 2 years developing MDX and its myriad of features including Anthem Room Correction Technology for each zone.
Nothing could be simpler than on-site configuration and calibration using our intuitive Web-based controls.
The specially designed, adaptive user interface works on any device. Custom configure zones, from input assignments to zone names. Adjust levels (and every aspect of performance) independently.
Robust IP/RS-232 connection capability ensures compatibility with leading home automation systems, with easily downloaded drivers.
Drivers available for these systems:
Dedicated Subwoofers For Each Zone
Install and control subwoofers independently in separate zones, with dedicated outputs (both low and high level, including bridge mode), and zone-independent settings for the new, more advanced Anthem Room Correction (ARC® Genesis).
Toggle ARC Genesis on/off in each zone to hear the benefits of premium room optimization.
Zone Configuration Options
Zones can have custom names, multiple inputs, independent playback, and tuning controls. Bridge zones for more power. Enable subwoofer bass management in any zone, instantly set crossover frequency, level, phase, and polarity.
Only the MDX Series gives you this much control over multiple zones, supporting more creative system designs and more thrilling audio performance.
Analog/Digital Matrix Switching
Full digital/analog matrix switching allows you to assign any analog RCA, digital coaxial or digital optical input to any output, either pre-configured via the web interface or switched in real-time via IP commands.
|Channels / Zones||8 channels / Up to 4 zones|
|Power Output RMS per Channel (8 Ohm)||60 Watts|
|Power Output RMS per Channel (4 Ohm)||120 Watts|
|High Output Mode (Bridged) RMS per Channel (8 Ohm)||200 Watts|
|Frequency Response||10Hz – 20kHz ±0.5dB|
|Digital-to-Analog Converter||PCM up to 24 bit/192 kHz|
|Inputs (analog)||4x RCA pairs (left/right)|
|Inputs (digital S/PDIF)||1x Optical|
|Inputs (network)||RJ-45 10Base-T/100
Base-TX ethernet port (female)
|Inputs (trigger)||1x 3.5mm (5 – 24V DC/AC)|
|Inputs (other)||Micro-USB (for ARC); RS-232|
|Outputs (speaker level)||4x removable Phoenix style (left/right) accommodate wire up to 12AWG|
|Outputs (subwoofer)||4x RCA (with bass management and room correction)|
|Outputs (other)||1x 3.5mm 12V trigger|
|Audio In-Out Matrix||Yes|
|Advanced Load Monitoring||Yes|
|Controls (via web-based UI)||Bass level: ±6dB for each zone;
Trebel level: ±6dB for each zone;
Level balancing: ±10dB for each zone
|Controls (back panel)||Power Mode: Auto, Trigger,
Network Reset (pinhole);
Factory Reset (pinhole);
Main Power: On /Off
|Room Correction||Anthem Room Correction (ARC®)|
|Microphone (for room correction)||Included dual input microphone
(3.5mm and mini-USB)
|Setup||Web-based user interface|
|IP Control (via IP or RS-232)||Drivers for Control4, Crestron, Savant, URC, Elan and RTI(coming soon)|
|Rack Mount Ears / Feet||Included|
|Rack Space (feet removed)||2U|
|Dimensions (H x W x D, with feet)||3.9” x 17” x 17” (9.9 x 43.2 x 43.2 cm)|
|Weight||21 lbs. (9.5kg)|
