Ultra high performance, technology and aesthetics

Formed from serious rethinking of loudspeaker design, the Vivid Audio B1 loudspeaker is any passionate audiophile’s dream.

The Vivid Audio B1 is a mid-sized, floor standing model and not your typical square box design, and for a good reason too.

Every aspect and component of this loudspeaker has been scrutinized and reinvented to create a dynamic and boxless sound.

The B1 features Vivid Audio’s patented drivers coupled to tapered tube absorbers for reaction cancelling.

Specifications

Configuration: 3 and 1/2 way vented cabinet

Cabinet material: Complex loaded carbon fibre filled polymer

Standard cabinet colour: Piano, Pearl

Bespoke cabinet colour: Bespoke colour options available on request

Drive units:

• HF: D26 — 26mm metal dome unit with Tapered Tube loading

• Mid: D50 — 50mm metal dome unit with Tapered Tube loading

• Bass: C125 — 2 x 125mm metal coned unit (coupled)


Bass loading: Dual reaction cancelling ports, bass reflex

Sensitivity: 89dB @ 2.83Vrms at 1.0 meter on axis

Nominal impedance: 4

Frequency range (Hz): - 6dB points: 35 - 36,000 Hz

First D26 frequency range: 44,000 Hz

Frequency response: 39 – 33,000Hz +/- 2dB on reference axis

Harmonic distortion (2nd and 3rd harmonics): < 0.5% over frequency range

Cross over frequencies (Hz): 100, 900, 3500

Power handling (music program) watts rms: 300

Loudspeaker dimensions: 1095mm (H) x 265mm (W) x 375mm (D Cabinet) x 420 (D Base)

Net weight: 38kg
