Magnetar

Magnetar UDP800 Universal Mutli Region Blu-Ray Disc Player

Magnetar UDP800 Universal Mutli Region Blu-Ray Disc Player

정가 $1,999.00
정가 $2,599.00 할인가 $1,999.00
할인 품절
배송료는 결제 시 계산됩니다.




Magnetar UDP800 Universal Blu-ray Disc Player

*Pre-order now for ship multi -zone shipment due in 2 - 3 weeks*

The Magnetar UDP800 is a high end universal blu-ray disc player specifically designed with high end video and audio in mind. The player features advanced image decoding and processing technology, with 4K ultra HD and HDR support, including Dolby Vision and HDR10+ providing clear and sharp picture and rich colours. The UDP800 features a metal chassis which is not only highly durable but provides an elegant high end look.

Key Features
• 4K UHD Blu-ray player
• Also plays BR, 3D BR, DVD, DVD-Audio, CD, SACD etc
• Supports HDR formats - Dolby Vision, HDR10+, HDR10
• Supports Dolby Atmos, DTS-X, Dolby TrueHD and DTS-HD Master Audio
• Play hi-res media from USB or NAS HDD, up to 16TBs
• Supports DLNA and SMB protocols
• DSD64/128, multi-channel DSD64, and 192kHz/24-bit PCM formats
• AIFF, ALAC, APE, FLAC and WAV audio file support
• 4-layer PCB circuit board with independent wiring
• Dual independent Burr-Brown PCM 1795 DACs
• Stereo XLR & RCA outputs for stereo audio
• Two-stage filter design with Japanese Rubycon electrolytic capacitors
• Independently shielded power supply and CD mechanism
• Brushed aluminium front panel and rigid metal chassis

Owner's Manual (PDF, 53.7MB)



Tony O’Brien spins up a seriously capable new universal 4K Blu-ray player

"Built like a battleship, the UDP800 is a reference-grade universal disc player. It produced outstanding images that outperformed my superb, reference Oppo UDP-203 4K player. While colour reproduction is first-class, where this machine really shines is the sharpness and clarity of the images that it produces. Meanwhile, blacks are deep and inky, devoid of any video noise."

Read the full Applause Award review at StereoNET Australia.



EISA HOME THEATRE DISC PLAYER 2023-2024

"For a high-quality AV experience, there is still nothing better than Ultra HD Blu-ray discs, especially when delivered by a premium player. Magnetar’s UDP800 is the star you need to illuminate your home theatre, combining DVD, Blu-ray and Ultra HD Blu-ray playback with handling of music formats including DVD-A and SACD. Comprehensive user menus and connectivity make this disc-spinner user friendly, while its high-end construction befits the price tag. The UDP800 delivers 4K discs (including Dolby Vision or HDR10+) with pin-sharp detailing and smooth colour gradations via HDMI, but switch to music though its analogue outputs (RCA or XLR) and its performance is equally captivating. The UDP800 is the long-awaited new king of discs."



Magnetar UDP800 disc player review

"On the movie side, no streaming version of any film can compare with 4K UHD disc playback in all its uncompressed glory. Serious movie fans will want a player that can maximize the experience and match the capabilities of their television and surround-sound setups.

I know you’ll be enthralled with the quality the UDP800 delivers with 4K UHD video and SACD audio, but I’m even more impressed with the experiences it delivers with DVDs and standard CDs. This player breathes new life into those aging and lower-resolution formats; it’s one of the most versatile investments you can make in your home theater."

Read the full review by James Barber on TechHive



Universal Disc Player

The UDP800 is a universal disc player, meaning it not only plays 4K blu-ray discs, but it also supports regular blu-rays, 3D blu-rays, DVDs, CDs, SACDs, and even media files with H265 & H264 support.

HDR Technology

The UDP800 supports high dynamic image formats such as Dolby Vision, HDR10 and HDR10 with stunning HDR to SDR conversion, with BT.2020/BT.709/BT.601 colour space support. HDR brings eye-popping brightness, contrast and gorgeous colours to your media, bringing out the full richness of each frame like never before*.

*Display and media must also support HDR formats.





4K Upscaling

With 4K upscaling, the UDP800 can convert low resolution video sources up to 4K 50/60Hz (3840 x 2160) resolution. Four times the resolution of full HD 1080p, enhancing your home video experience.

A Master of Audio

The UDP800 supports Dolby TrueHD and DTS-HD Master Audio, as well as Dolby Atmos and DTS-X, enabling you to enjoy the best panoramic and immersive sound experience.



High Fidelity Lossless Music

In addition, the UDP800 features support for high end audio playback. It can decode DSD64/128, multichannel DSD64, and 192kHz/24-bit PCM formats with FLAC, WAV, AIFF, ALAC and APE file support.

Premium Digital to Analog Converter

For Pure Audio playback, UDP800 specifically adopts a 4-layer PCB circuit board where each channel is designed with independent wiring. Two independent Burr-Brown PCM 1795 DAC processors are used for two-channel D/A decoding, processing left channel and right channel respectively, and high-quality MUSES8920 OP-AMPs for audiophile sound quality. The UDP800 features stereo XLR gold-plated balanced terminals and stereo RCA gold-plated unbalanced outputs. A bespoke "Pure Audio" mode function is available to bring uncompromised sound quality to music lovers.

High-Power Transformer

MAGNETAR employs a specially selected custom 60W high-power low noise transformer for the UDP800, with a two-stage filter design along with Japanese Rubycon electrolytic capacitors to meet the high transient response required by surround sound systems and high-resolution audio. Housed in it's own separate metal case to further lower noise levels, providing stability and silence, further improving audio and video quality.

Full Multimedia Experience

The UDP800 supports multiple disc and media formats, such as UHD-BD, BD, BD-R, BD-RE, DVD-R/RW, DVD+R/RW, DVD-Video, DVD-Audio, SACD, CD, CD-R/RW. In addition, USB HDDs up to 16TB are supported with direct access from your computer or NAS through your local network using DLNA or SMB protocols.

User Experience Interface

The UDP800 User Interface is designed to provide a smooth and intuitive experience, allowing easy access to various settings and local USB devices and networks.

Elegant & Solid Chassis Construction

Achieving exceptional audio and video performance requires high quality chassis construction and stability. The UDP800 provides a brushed aluminium front panel, in a solid highly rigid metal chassis to greatly improve audio and video performance. With a distinctive double layer chassis structure thickened to 1.6mm and a 3mm steel plate under its base, reducing vibration and generated noise during playback the UDP800 tips the scales at 8kgs!

Additionally, major internal components including the CD mechanism and power supply are independently shielded to reduce external magnetic fields. Simply put, Magnetar is high-end home entertainment at his best.



Specifications

Disc Type:
- UHD Blu-ray, Blu-ray, Blu-ray 3D, DVD-Video, DVD-Audio, AVCHD-SACD, CD, Kodak Picture CD, CD-R/RW, DVD±R/RW, DVD±R DL, BD-R/RE

Output:
- Analog audio: stereo
- Independent stereo analog audio: XLR balanced output, RCA output
- Optical/coaxial audio: up to 2 channels /192kHz PCM, Dolby Digital, DTS
- HDMI audio: up to 7.1 channel /192kHz PCM, up to 5.1 channel DSD, Bitstream
- HDMI video: UHD/p24 1080/1080p / 1080I / 720p / 576p / 576I / 480p / 480I

Analog Audio Characteristics:
- Frequency range: 20HZ-20khz (-3dB ~ +0.05dB)
- Signal-to-noise ratio: & GT: 120dBr
- Total harmonic distortion + Noise: & LT: 0.00018%
- Output level: (RCA) 2. l±0.2Vrms. (XLR) 4.2±0.4Vrms
- Dynamic range: AGT: 120dB
- Channel separation: & GT: 120dB

General specifications:
- Power supply: AC 100-240V ~, 50/60Hz
- Power: 30 W (Standby: 0.5W in energy saving mode)
- Size: 430 mm x 300 mm x 90 mm
- Weight: 8kg
- Working temperature: 41° F – 95° F 5° C – 35° C
- Working humidity: 15% – 75%
