Anthem AVM70 A/V Processor

Anthem



AVM70 A/V Processor

Since the AVM 50 and Statement D2 A/V Processors, music lovers and home theater enthusiasts have coveted Anthem’s premium surround separates. Featuring industry-leading room correction, expert management of the latest audio formats and robust integration; Anthem is the ultimate nerve center of any premium home theater or media room.


With the latest version of ARC Genesis Room Correction, a redesigned and more accurate calibration microphone, Anthem Web User Interface, an all-new electronics platform and a new modernized design; the new AVM A/V Processors bring all of today’s technologies into a single component.


Object-oriented audio codecs have been updated with support for up to 15.2 channels; as well as built-in streaming support for Apple AirPlay2, Google Chromecast, Bluetooth, Spotify Connect and Roon (coming soon).


Video support includes 7 HDMI 2.0 inputs with 2 outputs, plus eARC for seamless integration with smart TVs. Perfect passthrough of Ultra HD signals at up to 18.2 Gbps with Dolby Vision, HDR or Hybrid Log Gamma ensures optimal presentation of your visual media.





INTRODUCING ANTHEM WEB USER INTERFACE

Anthem Web User Interface is now built in to all MRX Receivers and AVM Processors. Using a phone, tablet or laptop, owners can easily access any function or setting and make changes on the fly. Power the main or second zone on and off, adjust volume, change audio modes or tweak channel trims for a perfect surround sound experience. Web UI can also be used to calibrate speaker delays and levels and configure network settings/control options. Source devices can be renamed, simplifying set up by enabling the elimination of unused inputs. Installers can import and export files to make remote management simple and convenient.



Robust Integration

The Anthem AVM 70 features external control and IP control capabilities for easy customization and compatibility with third-party integration solutions. It offers IP control capability for major third-party control devices including:



Design

At Anthem, we have one simple goal – to design, engineer and manufacture audio/video products that deliver premium performance and convenience at a reasonable price. We do this by spending thousands of hours selecting and testing components, carefully designing our own circuit topologies, and backing them with robust power supplies that ensure maximum long-term quality and reliability. We achieve this with our team at the Paradigm/Anthem Research Center and their decades of combined experience.



Limitless Possibilities

Today’s premium home theaters need support for as many as 15 speakers and 4 subwoofers to handle the latest Dolby Atmos and DTS:X object-oriented audio codecs. Pair an AVM 70 or AVM 90 A/V Processor with a stack of MCA amplifiers and you’ll hear sound that rivals the best commercial cinemas.


MCA’s scalability means you can purchase only the channels you need to power your vision of home entertainment. AVM Processors can now manage configurations up to 15.4 channels (up from 11.2) with ARC Genesis Room Correction ensuring the best possible sound at every seat. And you won’t need to hide your gear from view.


Anthem’s modernized design extends to every component in the MCA and AVM lines. All MCA power amps are Crafted in Canada.



PREAMPLIFIER (MEASURED AT XLR OUTPUT)
Maximum Output (<0.1% THD) 10.7 VRMS, Subwoofer 11 VRMS
Frequency Response 20 Hz — 35 kHz (+/-0.2dB)
Frequency Response, Analog-Direct 20 Hz — 80 kHz (+0, -2 dB)
THD+N (4 Vrms output) -100 dB
S/N Ratio (4 Vrms output, IEC-A filter) 110 dB
XLR Configuration Pin 1: Ground, Pin 2: Positive, Pin 3: Negative
POWER CONSUMPTION
Typical Load 60 W
Standby 0.3 W
Standby IP Control Enabled 1.8 W
Standby HDMI Bypass Enabled 4.9 W
DIMENSIONS
Height (without feet) 6" (15.24 cm)
Height with Rackmount Kit 4U
Width 17" (43.18 cm)
Depth (including wifi ant not power cord) 14-1/2" (36.4 cm)
Weight 22.1 lbs, 10.1 Kg
POWER REQUIREMENT
120 V version: In countries where the line voltage is 120 V, this product operates from a single phase AC power source that supplies between 108 V and 132 V at a frequency of 60 Hz.
220-240 V version: In countries where the line voltage is 220, 230, or 240 V, this product operates from a single phase AC power source that supplies between 198 V and 264 V at a frequency of 50 Hz.
