Accuphase E-800S Class A Precision Integrated Stereo Amplifier

Name: Accuphase E-800S Class A Precision Integrated Stereo Amplifier
Brand: Accuphase
Price: 26500.00 AUD
Availability: InStock

Inquire for Price

Accuphase

E-800S Class A Precision Integrated Stereo Amplifier

The E-800 is positioned above the E-650 as the new flagship model in the integrated amplifier lineup of Accuphase. The preamplifier section features the impeccable Balanced AAVA type volume control, while the power amplifier section is configured as an instrumentation amplifier using a six-fold parallel push-pull configuration of power MOS-FETs driven in pure Class A. The resulting quality is on a par with high-class separate type amplifiers. Operating as a simple and smart system, the E-800 realizes acoustic excellence that reaches to the very heart of the music.

Integrated amplifier with fully balanced configuration extending from input to output
Balanced AAVA type volume control
Power amplification stage configured as instrumentation amplifier
Six-fold parallel push-pull configuration of power MOS-FETs driven in Class A
Linear power progression of 50 watts into 8 ohms, 100 watts into 4 ohms, and 200 watts into 2 ohms
300 W output into 1-ohm load (music signals)
High damping factor of 1000
Strong power supply with massive high-efficiency toroidal transformer and large filtering capacitors
Protection circuitry using MOS-FET switches

Specification

Continuous Average Output Power (20 - 20000Hz)

(both channels driven)

1ohm load ( music signals)	300W
2-ohm load	200W
4-ohm load	100W
8-ohm load	50W

THD (20-20000Hz)

(both channels driven)

2-ohm load	0.05%
4 to 16 ohm load	0.03%

Intermodulation Distortion

0.01%

Frequency Response

HIGH LEVEL INPUT

*	20-20000Hz (+0,-0.5 dB)

MAIN IN

*	20-20000Hz (+0,-0.2 dB)
At 1 watt output	20-20000Hz (+0,-0.3 dB)

Damping Factor

1000 (with 8-ohm load, 50Hz)

Input Sensitivity, Input Impedance

Input

Input Sensitivity

For rated output

For 1 Watt output (EIA)

Input Impedance

HIGH LEVEL INPUT

100mV

14.2mV

20 kilohms

BALANCED INPUT

100mV

14.2mV

40 kilohms

MAIN IN, LINE

976mV

113mV

20 kilohms

MAIN IN, BAL

976 mV

113mV

40 kilohms

Output Voltage and Impedance

PRE OUTPUT

LINE	796mV	50 ohms
BAL	796mV	50 ohms

Gain

HIGH LEVEL INPUT -> PRE OUTPUT	18dB
MAIN IN -> OUTPUT	28dB

Tone Controls

Turnover frequency and adjustment range

Bass : 300 Hz	+- 10dB ( 50Hz)
Treble: 3 kHz	+- 10dB (20kHz)

Loudness Compensator

+6B (100 Hz)

Attenuator

-20dB

S/N Ration

Input

Input shorted (A weighting)

S/N ratio at rated output

S/N ratio

HIGH LEVEL INPUT

104dB

97dB

BALANCED INPUT

104 dB

97dB

MAIN IN

119 dB

101dB

Bar graph meters

Represents output voltage value ( dB) using 30 points ( with on/off switch)

Output Load Impedance

(terminals A or B driven)	2-16 ohms (1-ohm load permissible with music signals only)
(terminals A and b driven simultaneously)	4-16 ohms (2-ohm load permissible with music signals only)

Stereo Headphones

Suitable impedance: 9 ohms or higher

Power Requirements

120V, 220V, 230V AC (voltage as indicated on the rear panel), 50/60 Hz

Power Consumption

Idle	180W
In accordance with IEC 60065	390W

Maximum Dimensions

Width: 465mm (18.31")

Height: 239mm (9.41")

Depth: 502mm (19.76")

Mass

Net	36.0 kg (79.4lbs)
In shipping carton	45.0kg (99.2lbs)
