Nordost QNET7 Network Switch
Pickup available at Brisbane HiFi 202/14 Trafalgar St, Woolloongabba, 4102
Usually ready in 2-4 days
Nordost QNET7 Network Switch
Brisbane HiFi 202/14 Trafalgar St, Woolloongabba, 4102
14 Trafalgar Street
202
Woolloongabba QLD 4102
Australia
7-Port Flagship Audio Network Switch with Optical SFP Port | Brisbane HiFi Specialist
The Nordost QNET7 is a reference-grade unmanaged Layer-2 Ethernet switch designed specifically for demanding high-end digital audio and network streaming systems.
Building on the original QNET architecture, the QNET7 expands the platform with a larger aluminum chassis, seven network connections, an SFP optical interface, an 8-layer impedance-controlled PCB, nine independent low-noise power regulators, and dual temperature-compensated low-jitter clock oscillators.
At Brisbane HiFi, we recommend the Nordost QNET7 for audiophiles seeking to optimize the network infrastructure surrounding high-resolution streamers, music servers, NAS systems, and DACs across Brisbane, Queensland, and Australia.
Key Features & Audio Engineering Highlights
7-Port Specialized Network Topology
The QNET7 provides three distinct connection types:
Ports 1–5 — Gigabit Network Ports
- 1000BASE-T
- 100BASE-TX
- Auto-negotiating
- Intended for routers, NAS devices, and general network components
Port 6 — Dedicated Audio Port
- 100BASE-TX
- Optimized for connection to a primary audio streamer or DAC
Port 7 — SFP Interface
Supports compatible SFP transceivers for:
- Copper Ethernet
- Optical fiber
- Direct galvanic network isolation
This allows optical fiber to be incorporated directly into the network architecture without requiring a separate external media converter.
8-Layer Impedance-Controlled PCB
The multilayer circuit board uses controlled signal routing to help minimize:
- Electromagnetic radiation
- Inter-port crosstalk
- Signal reflections
- High-frequency interference
Nine Independent Ultra-Low-Noise Regulators
Nine dedicated power regulation stages isolate different internal network circuits, helping prevent power-supply noise from propagating between the PHY and MAC sections.
Dual Femtosecond Clocking Architecture
Two temperature-compensated, ultra-low-jitter clock oscillators provide precise timing for the network switching architecture.
Shielded Anodized Aluminum Chassis
The precision-machined rectangular aluminum enclosure provides a rigid, thermally stable platform while helping shield sensitive internal circuitry.
Upgradeable Linear DC Power
The QNET7 can operate from its supplied DC power adapter or be integrated with the optional Nordost QSOURCE Linear Power Supply for an upgraded power architecture.
Product Specifications
| Specification | Technical Detail |
|---|---|
| Device Type | Layer-2 Unmanaged Audiophile Ethernet Switch |
| Total Ports | 7 (6 × RJ45 8P8C, 1 × SFP Module Slot) |
| Gigabit Ports (1–5) | Auto-Negotiated 1000BASE-T / 100BASE-TX (Routers & NAS) |
| Audio Dedicated Port (6) | Auto-Negotiated 100BASE-TX (Optimized Low-Noise Streamer Output) |
| Optical / SFP Port (7) | Accepts 1000BASE-T Copper or 1000BASE-LX/SX Optical SFP Modules |
| Internal Power Supplies | 9 × Independent Ultra-Low-Noise Regulators |
| Clock Oscillators | Dual Femtosecond Temperature-Compensated Clocks |
| Dimensions (W × D × H) | 320 mm × 122 mm × 59.25 mm (12.6" × 4.8" × 2.33") |
| Weight | 1.65 kg (3.64 lbs) |
| Power Input | 5 V DC / 1 A (Compatible with Nordost QSOURCE) |
Why Choose Brisbane HiFi for Your Nordost Digital Setup?
- Brisbane HiFi Reference Showroom – Audition the QNET7 within a high-resolution streaming system and explore the benefits of incorporating optical network isolation.
- System Architecture Advice – Our specialists can advise on SFP optical runs, Ethernet cable selection, QSOURCE integration, and mechanical support options.
- Trusted Australian HiFi Destination – Supplying Nordost networking accessories throughout Queensland and Australia with genuine products, manufacturer warranty, and specialist support.
What’s Included in the Box
- 1 × Nordost QNET7 Network Switch Unit
- 1 × Standard Wall DC Power Supply
- User Manual & Official Nordost Warranty Documentation
