I-180 Integrated Amplifier
I-180 Integrated Amplifier
UNMATCHED AUDIO CONTROL
The Aavik I-180 integrated amplifier receives the inputs from your individual Hi-Fi devices and transforms these signals into an authentic musical experience. Therefore, the architecture of the new Aavik integrated amplifier boasts sophisticated high-end electronic components set in a state-of-the-art enclosure. Based on ample power supplies, the Aavik amplifier provides unprecedented dynamic speed, tight control and balanced stability, which creates persuasive and crystal clear soundstage images that express even the finest sonic details. The Aavik I-180 integrated amplifier represents great value with solid engineering principles and outstanding sonic capabilities.
AAVIK UMAC™ AMPLIFIER – UNMATCHED AUDIO CONTROL
Aavik utilises the patented UMAC™ amplifier technology. This technology was developed to avoid the design flaws of traditional switching amplifiers. UMAC technology primarily targets two areas of modulated amplifier design. The PWM (Pulse Width Modulation) generation is produced with sine wave modulation rather than the more common triangle modulation. The benefit is that sine waves create far less high frequency noise than triangles, no sharp corners, and thus require far less inductive filtering at the output. The lower inductance in the output gives the amplifiers a much better damping factor and thus a distinctly better control of the speakers. In addition, the advanced dual mixed mode feedback allows damping factors that are characteristic of only the very best linear amplifiers.
VOLUME CONTROL – AFFECTS THE SONIC EXPERIENCE
The Aavik line stage boasts a unique, inverted, virtual GND (Ground) amplifier topology, which provides the highest stability. The feedback gets so powerful that it allows to damp the signal to a gain lower than 1. This preserves the full signal with the lowest Signal to Noise Ratio – no matter if you turn the volume up or down. This will provide your loudspeakers with a clear and distinct information flow to make even the finest details of timbral and textural nuances audible on an extremely quiet sound stage.
PREMIUM TECHNOLOGIES FOR UNCONSTRAINED SIGNAL FLOW
Aavik heavily draw on the experience and extensive R&D of their sister company, Ansuz-Acoustics™. They employed their groundbreaking, effective noise cancelling technologies and fitted all models of their new range of electronics with Tesla coils, dither circuitry and anti aerial resonance coils. These innovative technologies are geared towards paving the way for an absolutely unconstrained signal flow. Aavik has also prepared the top and bottom surfaces on all Aavik series to best accommodate Ansuz Darkz™, which represent the most effective way of preventing mechanical vibrations.
RESONANT MODE POWER SUPPLY – QUIET BUT EXTREMELY POWERFUL
The new Aavik series is designed to ensure massive power resources with ultra-low noise. Unlike the square waves used by conventional switch mode power supplies, the new Aavik series boast a resonant mode design which is principally driven by sine waves. When more power is needed, the operating frequency increases, which, in turn, has the advantage that the power density also increases, thus allowing higher peak power when required by the music.
The noise floor in the raw power supply is extremely low but could be even further lowered by the ultra-low noise regulators supplying the different parts of the circuit. The noise of these regulators is measured in a few microvolts respectively nanovolts, which is significantly lower than the noise level of conventional regulators.
SCANDINAVIAN DESIGN AESTHETIC
The Aavik design language is Scandinavian understatement and expresses simplicity and minimalism featuring only a few buttons for logical operation. The multifunctional main knob allows simple navigation and control of the various functions. A distinguishing design feature of the new Aavik series is a huge red display, which makes it easy to read all details of the selected operational settings.
A CABINET WITH EXCELLENT SONIC QUALITIES
Aavik have designed the enclosure to minimise the use of aluminium and its associated mechanical resonance. Over the years, Aavik have been testing various materials and ultimately designed an innovative natural-based composite material, which reduces the mechanical influence, particularly the hysteresis. The sonic result is distinctly audible and reflects a further prominent cornerstone in Aavik’s quest for the ultimate music experience.
The Range of Aavik Integrated Amplifiers
Aavik have produced 3 levels of performance within the acclaimed I-180, I-280 and I-580. The I-180 represents great value with a high-end performance capability beyond its price level. The I-280 adds significantly more resonance control techologies resulting in an even lower noise floor, resolution and accuracy. The I-580 introduces the unique copper inner chassis, Titanium level resonance control, and the maximum Ansuz Acoustics resonance mitigation technology, taking performance to a statement level.
Aavik 180 Series—Danish High End Components
|Line||Gain (line 1-4: 5-15dB; maximum input 4.5V RMS
Gain (line 5: 1-11dB; maximum input 6.5V RMS
Input impedance 10K Ohm
|Pre-amp Output||1 pair of RCA output
Max output: 7.5Vrms
Distortion, line stage: <0.005% (THD at 1kHz, 1V input)
Output impedance: 50 Ohms
|Volume Control||76 1dB steps|
|Output||2 x 300W 8 Ohm, 2 x 600W 4 Ohm
Distortion (THD+N): <0.006% (1-100W, 1kHz, 8 Ohm
IMD: <0.002% (1-100W, 4 Ohm)
TIM: <0.008% (1-100W, 4 Ohm)
|Aavik Noise Reduction||Active Tesla Coils: 36
Active Square Tesla Coils: 96
Dither circuitry: 5
Anti-Aerial Resonance Coils: 4
|Power consumption||Standby: <0.5W
|Dimensions||102 x 384 x 400mm|
