Pass Labs

X600.8

The X600.8 monoblock amplifiers deliver 600 watts into 8 ohms. Even more impressive they effortlessly drive the most demanding loudspeakers to musical nirvana, be the performance full scale orchestra, high-decibel rock band or string quartet. Exhaustive listening tests, not myopic focus on specifications have informed the development of this and the rest of the Pass Labs product offering, and you can hear it.

Features

Class AB Operation: The amplifier operates in Class AB, known for a balance of efficiency and low distortion.

Power Output: Delivers 600 watts per channel into 8 ohms

Frequency Response: A wide frequency response from 1.5 Hz to 100 kHz, ensuring a faithful reproduction of the audio signal.

Damping Factor: A high damping factor of 200, which provides good control over speaker movements.

Input Impedance: Offers both single-ended (50 kOhms) and balanced (100 kOhms) input options.

Gain: A gain of 26 dB.

Dimensions and Weight: The amplifier has a footprint of 19 x 21.5 x 11 inches and weighs 123 lbs.

Distortion: Low distortion, with 1% at 1 kHz full power.

Specifications

• Class: AB
• Type: Mono
• Gain (dB): 26
• Full Pwr @ 26 dB gain (V): 3.46
• Low Frequency Response: 1.5 Hz
• High Frequency Response: 100 KHz
• Power Output /ch (8 ohm): 600
• Input Impedance (SE & BAL Kohms): 50/100
• Damping Factor: 200
• Power Consumption @ Idle (Watts): 600
• Unit Dimension (W x D x H) (In.): 19 × 21.5 × 11
• Unit Weight (LBS): 123
